INNOVV K7 Dashcam

Find all the information you need about the K7 Dashcam in here. This includes the APP, manuals, firmware, FAQs, and video tutorials.

How To Update Firmware

1. Format an 8-32GB TF/SD card to be FAT32 *in the K7 first*. Use the button below to “Download” the new firmware file (IN-K7-1.bin) to your desktop. Copy the firmware to the root of the TF card.

2. Insert the TF card into the camera DVR and turn on your vehicle, when the remote control blue and green lights will blink alternately. If the DVR finds a .bin file, it knows to execute an update. Please wait for the lights to go off, meaning the update is complete.

*Please do not power off or try to operate the K7 while it is updating. After a successful upgrade, the lights will turn off, and then the K7 will automatically restart and the red light will turn on solid. The firmware will be deleted from the TF/SD card once updating is finished so that it can be used to record videos.

Manual

Click the button below to download the manual

Manual

K7 Firmware Version:

IK7.20240705.V03-5G

Download

Changelog:

Optimize Correct the problem with flickering in the preview of screen delay and GPS indicator lights

FAQ

1. The camera is shaking during riding, and the videos are jittery.

Please check if the camera is parallel to the ground and confirm if the screws are tightened enough.

2. The video is blurry.

Please check if the lenses are clean without any finger marks, dust or other smudges, and wipe the lenses with dust-free cloth.

The DVR is not working with the motorcycle ignition on.

Please check the yellow ACC wire is connected correctly.

4. The Wi-Fi can not be found.

Please check if the blue light on the remote control is flashing. If the blue light is not on, turn off the ignition, shut down K7, then turn on the ignition and restart K7 to activate Wi-Fi.

5. Forget the Wi-Fi password.

Please long-press the Function Button on the Remote Control for 10 seconds to reset the K7 to the factory default settings. Then, reconnect the K7’s Wi-Fi using the default password 12345678.

6. There is no audio in the video.

1. Please check if the microphone is off in the App settings.
2. Please check if the microphone’s connector is loose or damaged in the wiring harness.

7. GPS indicator light flashes or is off.

1. Flashing light: Please make sure the GPS antenna is installed with a clear view of the sky. Make sure the text side is facing up, and that there is nothing blocking it.
2. Light off: Please check that the GPS antenna connector is not loose or damaged in the wiring harness.

8. Video frozen when it is played or downloaded in the App.

1. The distance between the phone and the DVR should be within 2 meters, and make sure there are no obstacles or sources of interference nearby.
2. Use the app on a mainstream mobile phone for a better experience.
3. Check whether the host is properly installed. Ensure that the text faces upward and no metal shell or cable blocks the host.
